Our Bulletin 1783 Stratix® 5400 Industrial Ethernet Managed Switches support layer 2 switching and layer 3 routing using a combination of Gigabit Ethernet (GE), Power over Ethernet (PoE) and GE fiber ports to help offer enhanced scalability. In addition, this switch offers DLR with three-ring support, which allows more connected devices at the Cell/Area Zone level for increased network design flexibility.
- Products
- Overview
- Documentation
Overview
- Supports layer 2 access switching and layer 3 routing for use in multiple layers of the architecture
- Includes Integrated Device Level Ring (DLR) with three-ring support to help increase network design flexibility for more complex machines
- Offers an all-Gigabit (GE) platform for high performance network support
- Offers support for dual GE switch ring configurations for high performance network resiliency
- Uses Studio 5000® Add-on Profiles (AOPs) to enable premier integration into the Rockwell Automation Integrated Architecture® system
- Includes embedded Cisco technology to help enable integration with the enterprise network
- Provides Integrated Network Address Translation (NAT) for 1:1 IP address mapping which helps to reduce commissioning time
Certifications
- cULus Marked
- CE Marked
- RCM
- Ex
- EtherNet/IP
Certifications apply when product is marked. See our Product Certification site for Declarations of Conformity, certificates and other certification details.
Tools & Resources
Recommended For You
You may also be interested in
Documentation
| Technical Specifications | パブリケーション |
|---|---|
| Stratix Ethernet Device Specifications | 1783-TD002_-EN-P |
| Installation Instructions | パブリケーション |
|---|---|
| Stratix 5400 Ethernet Managed Switches Installation | 1783-IN014_-EN-P |
| User Manuals | パブリケーション |
|---|---|
| Stratix Managed Switches User Manual | 1783-UM007_-EN-P |
| Ethernet Reference Manual | ENET-RM002_-EN-P |
| Program Guides | パブリケーション |
|---|---|
| EtherNet/IP Device Level Ring Application Technique | ENET-AT007_-EN-P |
| EtherNet/IP Parallel Redundancy Protocol Application Technique | ENET-AT006_-EN-P |
| Product Profiles | パブリケーション |
|---|---|
| Stratix 5400 Industrial Ethernet Switches Product Profile | ENET-PP012_-EN-P |
| Stratix 8000/8300 Modular Managed Ethernet Switch Migration Profile | MIGRAT-PP043_-EN-P |
| Miscellaneous | パブリケーション |
|---|---|
| Stratix Industrial Networks Infrastructure At-a-Glance Quick Reference | ENET-QR001_-EN-E |
