| Power |
10 j
|
|---|---|
| Type of current |
AC
|
| Nominal voltage |
120 V
|
| Flashing frequency |
1 Hz
|
| Current consumption |
48V DC @ 260mA (58V)
|
| With contact |
False
|
| Degree of protection (NEMA) |
4
|
|---|---|
| Degree of protection (IP) |
IP67
|
| List of degrees of protection (IP) |
IP67, IP66
|
| List of degrees of protection (NEMA) |
4, 4X, 13
|
| Code |
(Operating temperature, max) @ 55 °C (131 °F) ambient for Class III, Divisions 1 and 2 @ T4A (120 °C [248 °F])
|
| Operating temperature, max |
-20 °C
|
| Storage temperature, max |
-20 °C
|
| Suitable for wall mounting |
True
|
|---|---|
| Suitable for ceiling mounting |
True
|
| Mounting method |
Built-in
|
| Colour of lamp hood |
Other
|
| Lens color |
Amber
|
| Material housing |
Plastic
|
| Housing color |
Black
|
| Lamp type |
Xenon
|
|---|---|
| Size |
0.5 in NPT conduit entrance
|
| Shock |
30 G peak
|
| Vibration |
2 G peak
|
| Height, approx |
142 mm
|
| Width, approx |
172 mm
|
| Depth, approx |
232 mm
|
| Material of gasket |
Viton
|
|---|---|
| Material of beacon lens |
Glass
|
| Material of covers |
PPS glass-filled plastic
|
| Material of bases |
PPS glass-filled plastic
|
| Material of mounting bracket |
Stainless Steel 304 (A2)
|
| Material of beacon housing |
PPS glass-filled plastic
|
| Zeichnungen | |
|---|---|
| 3D STEP Model (STP) | Herunterladen (ZIP) |
| Zeichnungen |
|---|
| 3D STEP Model (STP) Herunterladen (ZIP) |
| Typ | Ressource | Veröffentlichung |
|---|---|---|
| Allgemein | Product Cutsheet | -- |
| Technische Daten | 855-td001_-en-p | 855-TD001 |
Suchen Sie nach weiterer Dokumentation?
Finden Sie kuratierte technische Dokumentation zu diesem Produkt im Technical Documentation Center oder durchsuchen Sie unsere vollständige Literaturbibliothek.
Suche in der Literaturbibliothek
- CE
- IECEx Scheme
- UL Listed Hazardous
- ATEX
Dieses Produkt erhielt die oben genannten Zertifizierungen zum Stichtag 2025-05-27. Produkte, die vor oder nach diesem Datum verkauft wurden, können andere Zertifizierungen aufweisen. Bitte überprüfen Sie das Produktetikett, um die Zertifizierungen Ihres Produkts einzusehen.
